More about Roto-Joint Technology….. UMI's Roto-Joint, short for Rotational Joint, allows 28 degrees of total rotation and unrestricted movement throughout the vehicles suspension. The Roto-Joint is designed to work like a spherical rod end while maintaining streetable qualities of a softer bushing. The Roto-Joint is designed to articulate and prevent suspension bind, and since the installed delrin race does not deflect like softer bushings, there is an improvement in traction and a significant reduction in wheel hop. The construction of the Roto-Joint features a 4140 chromoly, hard chrome plated spherical ball which rotates in a delrin race. The 4140 chromoly material and hard chrome plating are designed for extensive wear resistance against hard driving and accumulated miles. The spherical ball rotates in the CNC machined delrin bushing, which is contoured for the spherical ball to allow unrestricted movement as the ball rotates. Delrin is the bushing material of choice due to its high resistance against wear, great tensile strength, and ability to maintain its physical properties. The housing of the Roto-Joint features 4140 chromoly threads, and a CNC machined bushing holder TIG welded together for the utmost in strength and durability. The UMI Roto-Joint is adjustable and 100% rebuildable. This means as the delrin race wears the adjuster ring can be tightened using the optional spanner wrench to apply tension to the ball. If the delrin race would ever wear completely it can be replaced easily.
Fitment:
1982 Chevrolet Camaro
1982 Pontiac Firebird
1983 Chevrolet Camaro
1983 Pontiac Firebird
1984 Chevrolet Camaro
1984 Pontiac Firebird
1985 Chevrolet Camaro
1985 Pontiac Firebird
1986 Chevrolet Camaro
1986 Pontiac Firebird
1987 Chevrolet Camaro
1987 Pontiac Firebird
1988 Chevrolet Camaro
1988 Pontiac Firebird
1989 Chevrolet Camaro
1989 Pontiac Firebird
1990 Chevrolet Camaro
1990 Pontiac Firebird
1991 Chevrolet Camaro
1991 Pontiac Firebird
1992 Chevrolet Camaro
1992 Pontiac Firebird
1993 Chevrolet Camaro
1993 Pontiac Firebird
1994 Chevrolet Camaro
1994 Pontiac Firebird
1995 Chevrolet Camaro
1995 Pontiac Firebird
1996 Chevrolet Camaro
1996 Pontiac Firebird
1997 Chevrolet Camaro
1997 Pontiac Firebird
1998 Chevrolet Camaro
1998 Pontiac Firebird
1999 Chevrolet Camaro
1999 Pontiac Firebird
2000 Chevrolet Camaro
2000 Pontiac Firebird
2001 Chevrolet Camaro
2001 Pontiac Firebird
2002 Chevrolet Camaro
2002 Pontiac Firebird
|
| Air Freight Prohibited: false |
| Not Carb Approved: false |
| Carb Acknowledgement Required: false |
| Ltl Freight Required: false |
| Prop 65: Y |
| Part Type: automotive |
| Epa: N/A |
| Regular Stock: false |
| Units Per Sku: 1 |
